Lifting Capacity 载荷 (t) | Span 跨度 (m) | Lifting Height 起升高度 (m) | Work Duty 工作级别 | Lifting Speed 起升速度 (m/min) | Crane Traveling Speed 起重机运行速度 (m/min) | Trolley Traveling Speed 小车运行速度 (m/min) | Total Power 总功率 (KW) |
15 | 22.5~34.5 | 16 | A6 | 13.2 | 36.7 | 101.4 | 63 |
A7 | 15.8 | 36.6 | 103.9 | 79.5 | |||
20 | 22.5~34.5 | 15 | A6 | 12.6 | 36.2 | 89 | 71 |
16 | A7 | 15.8 | 42.8 | 103.9 | 94.5 | ||
32 | 22.5~34.5 | 15 | A6 | 12.5 | 37 | 87.3 | 111.3 |
16 | A7 | 15.1 | 43.3 | 104.3 | 135.5 | ||
40 | 22.5~34.5 | 16 | A6 | 11.7 | 37.5 | 87.3 | 128.5 |
A7 | 15.3 | 43.2 | 113.9 | 173 |
